THREE PHASE
FEATURES
SPECIFICATIONS
Input power voltage (V) 3-400
Frequency (Hz) 50/60
Effective input current (A) 18
Maximum (KVA) 13.5
Current adjustment range (A) 20-65
Maximum no-load voltage (V) 450
Duty cycle (A) (40°C 10 min) 90% @ 65
100% @ 61
Severance cut for carbon steel (mm) ≤35
Production cut for carbon steel (mm) ≤25
stainless steel (mm) ≤25
aluminium (mm) ≤20
copper (mm) ≤14
Air operating pressure (psi) 50-90 (3.5-6 bar)
Air operating flow 160
Protection class (l/min) Ip23 (5.65 cfm)
Insulation class H
Cooling Air
Overall dimensions (mm) 640 x 240 x 445
Weight (kg) 24
Accessories included 3m earth return lead, 3m gas hose
